Analyzer, Electrolyte, ISE-3000, Na+, K+, Cl-
- Ion Selective Electrode direct measurement
- Manometric method for TCO2
- 150 µl: Whole blood, serum, plasma and urine
- Specific modes for urine and lipemic serum
- 60 tests per hour without TCO2
- 45 tests per hour with TCO2
- Two levels with optional auto sampler
- One level without auto sampler
- Automatic: 2 points every 4h or on demand
- 256 patient files x 5 parameters each
- 5” LCD touch screen with monochrome display
- Temperature 15°C – 32°C
This price is inclusive of 5% commercial tax.
Description
Optimized Efficiency
Thanks to its automatically performed 2 point calibration every 4 hours, results are accurate with good reproducibility through time (automatic curve compensation is available). 1 point calibration is also ensured with every sample. Optional barcode reader allows for quick and easy identification of samples.
User-friendly Operations
The interactive touch screen, large display and user-friendly interface make for a trouble-free and effortless working experience. All ISE models are equipped with a 24 hour non-stop working mode suitable for emergency sample analysis. The built-in operating system alerts operators when reagent levels are low or a new pack is required. Electrodes and reagent packs snap in and out for easy replacement. Error alerts appear on print-out if values are abnormal.
Automation and Auto Sampling
Automation for high productivity is guaranteed by the automatic control software for aspiration, washing and calibration. Results display and print-out automatically. All models can be upgraded to ensure higher automation thanks to the optional auto sampler. Operators can program a series of up to 20 tests at one time, all the while being able to run emergency tests if necessary. All results can be transferred to lab’s IT network via mono directional LIS. With its programmable tests, and disposable cups, the auto sampler makes for a hassle-free work process.
Reagent Pack
The ISE SERIES is manufactured with a built-in disposable all-in-one reagents pack for quick and easy replacement of reagents. Each Pack contains 1 L of solution and is automatically identified by RFID. No liquid handling is necessary; no risk of hook-up errors can be made. The waste bag is integrated in the Pack, eliminating any risk of contamination.
TECHNICAL SPECIFICATIONS
| PRINCIPLES | Ion Selective Electrode direct measurement Manometric method for TCO2 |
| SAMPLES | 150 µl: Whole blood, serum, plasma and urine Specific modes for urine and lipemic serum |
| Quality Control | Two levels with optional auto sampler One level without auto sampler |
| THROUGHPUT | 60 tests per hour without TCO2 45 tests per hour with TCO2 |
| Calibration | Automatic: 2 points every 4h or on demand |
| MEMORY STORAGE | 256 patient files x 5 parameters each Transfer LIS mono-directional |
| REAGENTS PACK | Shelf life: 12 to 18 months Standard Pack: Cal A, Cal B, Waste Pack for ISE 4000 & 6000: Cal A, Cal B, TCO2 reagent |
| ELECTRODES | Long life: up to 5 years (6 months for Ca2+) 12 month warranty (6 month warranty for Ca2+) |
| DISPLAY | 5” LCD touch screen with monochrome display |
| OPERATING ENVIRONMENT | Temperature 15°C – 32°C Humidity < 85% (max humidity) |
| POWER REQUIREMENTS | A.C. 110/220 V ±10%; 50 – 60 Hz Power : < 60 W |
| DIMENSIONS | 390(W) x 445(H) x 340(D) mm |
| WEIGHT | Main unit : 10 kg; Auto sampler : 1.5 kg |
For detailed specifications refer to the Product Brochure.
SFRI
ISE-3000
The SFRI ISE SERIES is a wide range of fully automated electrolyte analyzers, that allows laboratories to perform accurate and reliable measures of electrolyte levels in the blood and urine. The analyzers are powerful independent tools designed to quickly and efficiently conduct basic electrolyte testing, without the need for any external resources, or additional computing power.
The ISE SERIES can measure up to 7 different parameters: Sodium, Potassium, Chloride, Calcium, Lithium and pH levels using Ion Selective Electrode technology; and Bicarbonates (TCO2) using the Manometric method. It also automatically calculates Total Calcium and the Anion Gap, useful in emergency and intensive care medicine. The series is composed of 6 different instrument models, each designed to specifically target different laboratoryneeds.
