CL-300, Lensmeter
Our Price
- The large, designed color LCD monitor with a 5.7-inch touch panel simplifies the interpretation of readings even with progressive and multi-focal lenses.
- The dynamic color measuring graphics follow the measuring process and present each step of the operation with different color, providing better control and ease of use.
ကွန်ပျူတာစက်ဖြင့် လူနာများသုံးစွဲနေသော အသုံးပြုမည့် မျက်မှန်၏ပါဝါနှင့် မျက်မှန်သား၏ UVဖောက်နိုင်သော စွမ်းအားတို့ကို တိကျ၊ လျင်မြန်၊ မှန်ကန်စွာ အဖြေထုတ်ပေးနိုင်သောစက် ဖြစ်ပါသည်။
Ready to Ship
Description
- LCD color touch panel
- Compact slim body
- Automatic mono- & multi-focal detection
- UV transmittance measurement
- Green measurement light beam
- PD measurement (PDL model)
- LAN connectivity (PDL model)
Product Information
| Sphere | 0 to ±25D (0.01/0.12/0.25D steps) |
| Cylinder | 0 to ±10D (0.01/0.12/0.25D steps) |
| Axis | 0° to 180° (1° step) |
| Addition | 0 to +10D (0.01/0.12/0.25D steps) |
| Prism | 0 to 10Δ |
| Cylinder mode | MIX / – / + |
| Prism mode | X-Y (Orthogonal Coordinates), P-B (Polar Coordinates), No Display |
| UV transmittance | 0 ~ 100% (1% / 5% steps) |
| Lens detection | AUTO for single & progressive lenses |
| Contact lens measurement | Hard / Soft contact lens |
| Light source | Green LED 535±5 nm UV LED 365±5 nm |
| Wavelength criterion | e-line / d-line with ABBE compensation |
| Lens diameter | ø5 to 100 mm |
| Screen | 5.7 inch color TFT-LCD touch screen |
| PD measurement range | 50-90 mm |
| External interface | RS-232C × 2, LAN × 1 |
| Power supply | 100-240V / 50-60 Hz 1.2A (AC Adapter): AUTO power save |
| Dimensions | 197 mm (W) x 220 mm (D) x 404 mm (H) |
| Weight | 3.8 kg |
For detailed specifications refer to the Product Brochure.
Eye Care Equipment
CL-300
The large, designed color LCD monitor with a 5.7-inch touch panel simplifies the interpretation of readings even with progressive and multi-focal lenses. The dynamic color measuring graphics follow the measuring process and present each step of the operation with different color, providing better control and ease of use.
Out Stock
