DRI OCT Triton Plus (Remark- tender winning list)
- The DRI OCT Triton combines Swept Source OCT and eye tracking with multimodal fundus imaging in an all‑in-one state‑of‑the-art imaging tool.
- The Triton brings the next level of diagnostic capability to you and your patients.
Description
Unprecedented Image Quality
Triton’s Swept Source OCT, with a scanning speed of 100,000 A‑scans/sec and 1,050nm wavelength light source, results in stunningly clear and detailed images. You will not only see the retina and vitreous, but also the choroid and the sclera like never before!
Remarkable Diagnostic Capability
Seeing deeper makes it possible to have a better understanding of many ocular pathologies. Combined with unique features such as Spaide autofluorescence filters, Fluorescein Angiography and en face imaging,1 Triton empowers you to take proactive steps to preserve your patients’ eye health.
A Trusted Brand
The Triton has become a trusted brand and recognized leader in Swept Source OCT around the globe. With thousands of units in place, doctors are choosing the Triton for its unprecedented image quality, remarkable diagnostic capabilities, and clinical efficiencies.
Triton Product Lineup
The Triton is available in the standard model, the DRI OCT Triton, which includes Swept Source OCT, color fundus imaging, red-free, and optional anterior segment OCT imaging. There is also a DRI OCT Triton Plus model, which incorporates all of the above plus fluorescein angiography (FA) and fundus autofluorescence (FAF) imaging.
OCT Imaging
| Methodology | Swept Source OCT |
| Optical Light Source | Swept Source tunable laser at 1,050nm |
| Scan Speed | 100,000 A-Scans per second |
| Lateral Resolution | 20 μm |
| In-depth Resolution | Optical resolution: 8 μm, 2.6 μm digital resolution |
| Photography Type | Color, FA, FAF, Red-free |
| Picture Angle | 45° Equivalent 30° (Digital Zoom) |
| Operating Distance | 34.8mm |
| Minimum Pupil Diameter | Ø2.5mm OCT, 3.3mm fundus photo |
| Scanning Range (on fundus) | Horizontal Within 3 to 12mm Vertical Within 3 to 12mm |
| Scan Patterns | 3D scan (12x9mm, 7x7mm, 3x3mm) Linear scan (Line-scan/Cross-scan/Radial-scan) |
| Fixation target | Internal fixation target: Dot matrix type organic EL The display position can be changed and adjusted. The displaying method can be changed. Peripheral fixation target: This is displayed according to the internal fixation target displayed position. External fixation target |
| Photography type | IR |
| Operating distance | 17mm |
| Scan range (on cornea) | Horizontal Within 3 to 16mm Vertical Within 3 to 16mm |
| Scan pattern | 3D scan Linear scan (Line-scan/Radial-scan) |
| Fixation target | Internal fixation target External fixation target |
| Power Source | Voltage: 100-240V Frequency: 50-60Hz |
| Power input | 250VA |
| Dimensions | 320-359mm(W) X 523-554mm(D) X 560-590mm(H) |
| Weight | 21.8 kg (DRI OCT Triton) 23.8 kg (DRI OCT Triton plus) |
For detailed specifications refer to the Product Brochure.
TOPCON
DRI OCT Triton Plus
The DRI OCT Triton combines Swept Source OCT and eye tracking with multimodal fundus imaging in an all‑in-one state‑of‑the-art imaging tool. The Triton brings the next level of diagnostic capability to you and your patients.
