Flow Table Apparatus
Our Price
- For determining the consistency of concrete having high or very high workability.
- The apparatus consists of a double wooden table measuring 700 x 700 mm and hinged at one side.
- The top table is covered with a flat metal plate 2 mm thick, inscribed, and protected against corrosion.
- The galvanized steel cone with dimension of 130 mm upper diameter x 200 mm bare diameter x 200 mm height.
Ready to Ship
Description
Technical Specifications:
| Standard | UNI 8020-B, DIN 1048, BS 1881-105, EN 12350-5 |
| Dimension | 700 (L) x 700 (W) x 100 (H) mm |
| Approx. Weight | 24 kg |
Technical Specifications:
| Model Number | Parts Description | Qty |
| NL 4003 X / 001 – P 001 | Conical Mould | 1no. |
| NL 4003 X / 001 – P 002 | Wooden Tamping Rod | 1no. |
| NL 4003 X / 001 – P 003 | Standard Flow Table | 1no. |
For detailed specifications refer to the Product Brochure.
NL Scientific
Flow Table Apparatus
For determining the consistency of concrete having high or very high workability. The apparatus consists of a double wooden table measuring 700 x 700 mm and hinged at one side. The top table is covered with a flat metal plate 2 mm thick, inscribed, and protected against corrosion. The galvanized steel cone with dimension of 130 mm upper diameter x 200 mm bare diameter x 200 mm height.
